Yuchai 2000KW generator set

Categories：	Diesel generator set
Brand：	Yuchai series
Configuration：	Open-frame unit

Back to List

Diesel generator set parameters:

National II series:

Diesel generator set parameters:
model	FFDL-Y200GF	Unit power (KW)	200
Output voltage (V)	400/230	Rated output current (A)	360
Wiring method	Three-phase four-wire	Power factor	0.8 (Lag)
Startup method	24V DC start	Frequency (Hz)	50
Unit weight (kg)	2800	Unit dimensions (reference values)	*310011001750mm*
Altitude (m)	1500	Steady-state voltage regulation	≤±2.5%
steady-state frequency regulation	≤±5%	steady-state voltage fluctuation	≤±1%
Steady-state frequency volatility	≤±0.5%	Transient voltage regulation	-15% to +20%
Transient frequency regulation	-10% to +10%	Voltage settling time	≤1S

Diesel engine parameters
Diesel engine brands	Guangxi Yuchai	model	YC6MK350L-D20
Rated speed (pm)	1500	Power (kW)	235/258.5
Number of cylinders	6 cylinders	Cylinder arrangement	inline
*Cylinder bore stroke (mm)**	*123145**	Compression ratio	17.5:1
Speed adjustment method	Electronic speed control	fuel supply method	direct injection
fuel	China 0# light diesel oil	Fuel consumption rate (g/kw.h)	≤195
intake method	Supercharged, intercooled	Oil consumption rate (g/kw.h)	≤1
steady-state rate of adjustment	≤5%	Emission standards	China Ⅱ
Cooling method	Water tank radiator that meets ambient temperature requirements up to 40℃, belt-driven cooling fan, with fan safety cover.

Generator parameters

Generator brand: Wuxi Stanford

Manufacturer: Cummins Generator Technology (China) Co., Ltd.

Generator model: UCI274J1

Capacity: 230KVA

Voltage: 400V/230V

Types: Brushless, single bearing, rotating magnetic field

Excitation system: self-excited, automatically regulating voltage

Winding structure: 2/3 pitch

Number of phases: Three-phase four-wire

Insulation class: Class H

Power factor: COSΦ = 0.8 lag

Telephone interference factor: TIF: <50

Wiring: Y-type connection

Telephone harmonic distortion (THF): <2%

Protection rating: IP23

Radio interference: Meets BS800 and VDE G and N levels

Meets the following standards: GB755, BS5000 Part 3, VDE0530, NEMA MG1-22, IEC-34, GSA C22-100, AS1359

National III series:

Diesel generator set parameters:
model	FFDL-Y200GF	Unit power (KW)	200
Output voltage (V)	400/230	Rated output current (A)	360
Wiring method	Three-phase four-wire	Power factor	0.8 (Lag)
Startup method	24V DC start	Frequency (Hz)	50
Unit weight (kg)	2800	Unit dimensions (reference values)	*310011001750mm*
Altitude (m)	1500	steady-state voltage regulation	≤±2.5%
steady-state frequency regulation	≤±5%	steady-state voltage fluctuation	≤±1%
Steady-state frequency volatility	≤±0.5%	Transient voltage regulation	-15% to +20%
Transient frequency regulation	-10% to +10%	Voltage settling time	≤1S

Diesel engine parameters
Diesel engine brands	Guangxi Yuchai	model	YC6MK350-D30
Rated speed (pm)	1500	Power (kW)	235/259
Number of cylinders	6 cylinders	Cylinder arrangement	inline
*Cylinder bore stroke (mm)**	*123145**	Compression ratio	16.8:1
Speed adjustment method	Electrically controlled high-voltage common rail	fuel supply method	Electronic fuel injection
fuel	China 0# light diesel oil	Fuel consumption rate (g/kw.h)	≤201
intake method	Supercharged, intercooled	Oil consumption rate (g/kw.h)	≤1.5
steady-state rate of adjustment	≤5%	Emission standards	China III
Cooling method	Water tank radiator that meets ambient temperature requirements up to 40℃, belt-driven cooling fan, with fan safety cover.
